• This 5-axis control function gives smooth control of feed, cut, wedge-pitch, push-pitch, and outer coil diameter.
• The crank slide mechanism allows for highspeed production.
• By incorporating the mechanical parts into the machine, you have more control of the coiling space within the mechanical frame.
• Outer coil diameters up to ø28 mm are available.

• The MEC original spring program MNO2 easily organizes important statistics about the machine, including program flow, operating status of each axis, inputs/outputs, jump, etc., as with our other spring machines.
• The program editing function has greatly evolved, and the navigation system function and touch screen make it easier to create programs and shor ten the setup time.
• The coil number program allows to easily change feed, pitch, outer coil diameter, and initial tension on the advanced pitch diagram screen, making it easier to adjust basic coils.
• The automatic function of coil length correction is based on the capacitance length measurement method. The multi-functional production management system gives easy-to-control production.

Enables the taper tilt to be managed with a value from 0 to 100. Suitable for load adjustment in addition to shape adjustment, as fine adjustment can be performed in 100 levels.

Unit for left-hand coiling, bracket for initial tension servo motor, single point, and contact sensor for coil length measure are available as optional features.

The operating status of machine can be monitored through mobile phones or computers, and regular maintenance with preventive maintenance functions can contribute to improved production efficiency.
