AMADA MACHINERY
Blades
Circular Saw Blades
Carbide Tipped Circular Saw Blade
TCB-PT II

Carbide Tipped Circular Saw Blade
Circular saw blade suitable for cutting structural steel pipes.
Features
- ■ Feature(1) : Edge material specifications
-
- Uses cermet tips with excellent wear resistance and deposition resistance.
- ■ Feature(2) : Target materials
-
- Circular saw blade with the number of teeth increased for stably cutting thin-walled pipes.
Lineup of Products
Name | TCB-PTII | TCB-PT | |||||||
Outer diameter(mm) | Inner diameter(mm) | Blade thickness(mm) | Number of teeth | ||||||
60 | 80 | 100 | 100 | 120 | 140 | 160 | |||
250 | 32 | 2.0 | ● | ● | |||||
285 | 32 | 2.0 | ● | ● | ● | ● | |||
285 | 40 | 2.0 | ● | ● | ● | ● | |||
360 | 40 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | ●(2.5) | ●(2.5) |
● : Standard item
Specifications, appearance and equipment are subject to change without notice by reason of improvement.
This products is for Japan domestic market.
