Circular Saw Blades
Carbide Tipped Circular Saw Blade
TCB-SU II
Carbide Tipped Circular Saw Blade
Circular saw blade suitable for cutting stainless steel materials.
Features
- ■ Feature(1) : Edge material specifications
-
- Uses carbide tips with high toughness.
- ■ Feature(2) : Target materials
-
- Minimized adhesion of chips to prevent tooth chipping caused by chip inclusion with cutting stainless steels.
Lineup of Products
| Name | TCB-SUⅡ | |||||||
| Outer diameter（mm） | Inner diameter（mm） | Blade thickness（mm） | Number of teeth | |||||
| 40 | 54 | 60 | 72 | 80 | 100 | |||
| 240 | 32 | 1.75 | ● | ● | ||||
| 285 | 32 | 2.0 | ● | ● | ||||
| 285 | 40 | 2.0 | ● | ● | ||||
| 360 | 40 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | |||
| 360 | 50 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | |||
| 460 | 50 | 2.7 | ● | ● | ||||
● : Standard item
Specifications, appearance and equipment are subject to change without notice by reason of improvement.
This products is for Japan domestic market.
