AMADA MACHINERY
Blades
Circular Saw Blades
Carbide Tipped Circular Saw Blade
TCB-CR II
Carbide Tipped Circular Saw Blade
Circular saw blade suitable for cutting general mild steel materials such as structural steel.
Features
- ■ Feature(1) : Edge material specifications
-
- Uses cermet tips with excellent wear resistance and deposition resistance.
- ■Feature(2) : Target materials
-
- Stable life and cutting quality is provided with cutting structural carbon steels and structural alloy steels up to C ≤ 0.45%.
Lineup of Products
| name | TCB-CRII | |||||||
| Outer diameter（mm） | Inner diameter（mm） | Blade thickness（mm） | Number of teeth | |||||
| 40 | 54 | 60 | 72 | 80 | 100 | |||
| 240 | 32 | 1.75 | ● | ● | ||||
| 250 | 32 | 2.0 | ● | ● | ● | |||
| 285 | 32 | 2.0 | ● | ● | ||||
| 285 | 40 | 2.0 | ● | ● | ||||
| 360 | 40 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | |||
| 360 | 50 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | |||
| 380 | 40 | 2.6(2.5) | ●(2.6) | ●(2.5) | ●(2.5) | |||
| 460 | 50 | 2.7 | ● | ● | ||||
● : Standard item
Specifications, appearance and equipment are subject to change without notice by reason of improvement.
This products is for Japan domestic market.
